Overview

Part of Siemon’s 10G ip™ Cabling Solution, XGLO fiber optic cable assemblies are ideal for next generation backbone or fiber-to-the-desk applications. XGLO cable assemblies feature premium fiber that meets IEEE 802.3 10 Gigabit Ethernet Standard as well as IEC-60793-2-10 and TIA-492AAAC specifications for laser bandwidth Differential Mode Delay (DMD) specifications. In addition, these assemblies offer a superior connector polish that exceeds all ANSI/TIA/EIA and ISO/IEC insertion loss and return loss requirements.

These precision cable assemblies are warranted for 20 years and ensure optimum applications support for 10 Gigabit Ethernet serial transmission when installed in a qualified XGLO system. SC, LC and SC-LC hybrids available.

• Robust Performance — Laser bandwidth optimized cable reduces impurities in the core of fiber, ensuring robust 10 Gigabit Ethernet transmission
• Standard Lengths — Jumpers available in 1, 2, 3, and 5 meter standard lengths
• Easy Identification — Connectors color coded per ANSI/TIA/EIA-568-B.3
• Dust Caps — Dust caps included to protect polished ferrule from dirt and damage
• Polarity Connection — SC duplexing clip allows for polarity correction
• Durable — Exceeds TIA/EIA and ISO/IEC requirements for aging, exposure to humidity, temperature extremes, impact, vibration, coupling strength, and cable resistance to stress and strain
• Multimode and Singlemode — 50/125µm multimode and singlemode assemblies available
• Pigtails — Available in 1 meter lengths
• Supports 10 Gigabit Ethernet

Part of the XGLO (10 Gb/s) Fiber cabling system.

Part Numbers

FJ2-LCLC5L-(XX)AQ (Picture) LC to LC aqua duplex jumper, multimode

FJ2-LCSC5L-(XX)AQ (Picture) LC to SC aqua duplex jumper, multimode

FJ2-LCULCUL-(XX) (Picture) LC to LC yellow duplex jumper, singlemode

FJ2-LCUSCUL-(XX) (Picture) LC to SC yellow duplex jumper, singlemode

FJ2-SCSC5L-(XX)AQ (Picture) SC to SC aqua duplex jumper, multimode

FJ2-SCUSCUL-(XX) (Picture) SC to SC yellow duplex jumper, singlemode

FP1B-LC5L-01AQ (Picture) LC simplex pigtail, 900 micron, aqua, buffered, 1m (3.3 ft.), multimode

FP1B-LCUL-01 (Picture) LC simplex pigtail, yellow, 900 micron, buffered, 1m (3.3 ft.), singlemode

FP1B-SC5L-01AQ (Picture) SC simplex pigtail, 900 micron, aqua, buffered, 1m (3.3 ft.), multimode

FP1B-SCUL-01 (Picture) SC simplex pigtail, yellow, 900 micron, buffered, 1m (3.3 ft.), singlemode

Note:

FJ2-SCSC5L-(XX)AQ, FJ2-LCLC5L-(XX)AQ, FJ2-LCSC5L-(XX)AQ - Use (XX) to specify length: 01 = 1m (3.3 ft.), 02 = 2m (6.6 ft.), 03 = 3m (9.8 ft.), 05 = 5m (16.4 ft.)

FJ2-SCUSCUL-(XX), FJ2-LCULCUL-(XX), FJ2-LCUSCUL-(XX) - Use (XX) to specify length: 01 = 1m (3.3 ft.), 02 = 2m (6.6 ft.), 03 = 3m (9.8 ft.), 05 = 5m (16.4 ft.)
